Printing Technology |
24
pin serial dot matrix printer |
Printing speed |
max: 600 cps
|
15 cpi |
12 cpi |
10 cpi |
Draft |
600 cps |
480 cps |
400 cps |
LQ |
200 cps |
164 cps |
133 cps |
|
Line
Length |
94 columns @ 10
cpi
112 columns @ 12 cpi
141 columns @ 15 cpi |
Paper Handling |
Single sheet, passbook, envelopes,
labels
Passbook:max thickness 2.7 mm (while open),
other
paper type: up to 0.65 mm
Single Sheet Width: 65 - 244 mm
Single Sheet Length: 70 - 470 mm
|
Copies |
1 +6 |
Special functions |
Automatic Gap Adjustment (AGA), Auto
Alignment, Auto Border Recognition, Optical Mark
Reading,
Horizontal and Vertical Passbook Handling, Automatic
set-up (automatic recognition of marked values)
|
Graphic resolution
(dpi) |
60,120,180, 240, 360 (horizontal)
72, 90, 180, 216, 360 (vertical) |
Vertical spacing |
6-8-12 lines/inch - 3-4-6-8-12
lines/30mm - n/60, n/72, -n/180 - n/216 -n/360 per
inch |
Horizontal spacing |
5, 6, 7.5, 8.5, 10, 12, 15, 17.1,
20, 24 cpi and proportional |
Barcodes |
UPC/A, UPC/E, EAN8, EAN13, Code 39,
Code 128, Postnet, Codabar, ADD-ON 2, ADD-ON 5, Code
11, Code 93, BCD, MSI, 2/5 Interleaved, 2/5 Matrix,
2/5 Industrial |
Character set |
Code Page:PC standard set (CS1-CS2)
- 13 National Epson set - CP437 (USA) - CP437G
(Greek) - CP850 (Multilanguage) -
CP851 (Greek) - CP852 (Latin 2) - CP853 (Turkish) -
CP855 (Russian) - CP857 (Turkish) - CP858 (Euro) -
CP860 (Portuguese) -
CP862 (Hebrew) - CP863 (French/Canadian) - CP864
(Arabic) - CP865 (Norwegian) - CP866 (Cyrillic) -
CP867 (Turkish) - CP876
(OCRA) - CP877 (OCRB) - CP1250 (Central Europe) -
CP1251 (Cyrillic) - CP 1252 (Windows Latin1 Ansi) -
Gost - Tass - Mazowia -
ISO 8859/1/2/3/4/5/6/7/8/9/15 - 96GREEK - Ukrainian
- ID 12 - ID 14 - ID 17 - CP1098
(Farsi Arabic) - Roman 8 - CP
437
Slavic - Sanyo- Ku - PhilipCompuprint Character CS000
- CS010 International, CS020
Germany, CS030 Portugal, CS040 Spain1,SetCS050
Denmark/Norway, CS060 France, CS070 Italy, CS080
Sweden/Finland, CS090 Switzerland, CS100 Great
Britain, CS110 USA ASCII,
CS140 Greece, CS150 Israel, CS170 Spain 2, CS200
Jugoslavia, CS410Compuprint SP 40 plus TCV 370, CS510 SDC, CS520
Turkey, CS540 CIBC,
CS680 OLI-UNIX, CS701 PC-220 Spain2, CS711
PC-Denmark/Norway, CS712 PC-Denmark OPE, CS771
PC-210 Greek |
Resident font |
Draft, Courier, Gothic, Prestige,
Presentor, Script, OCR-A, OCR-B, Boldface |
Resident Emulations |
IBM ® Personal Printer 2390+,
Proprinter XL24E, Proprinter XL24E-AGM and Epson ®
LQ2550/LQ1170,
IBM ® 4722,Compuprint SP 40 plus ® PR40 plus/PR2/PR2845, IBM
9068, HPR 4915 |
Interfaces |
Parallel IEEE 1284 bidirectional,
Serial RS-232 C (Automatic Interface Switching), USB
2.0
Specific versions with Ethernet 10/100, dual Serial
Input buffer up to 64 Kbytes
Plug&play (Windows environments) |
Reliability |
MTBF: 10.000 hours |
Print Head Life |
400 million characters |
Ribbon life |
Black ribbon cartridge: 5 million
characters or long life 15 million characters |
Noise Level |
< 55dbA |
Power Supply |
Universal from 100 to 230 V
Frequency: 60Hz / 50Hz |
Power consumption |
75 W max. (printing), 7 W (standby)
|
Physical Dimensions & Weight |
400 (W) x 200 (H) x 295
(D) mm - <12 Kg |
|
